AGM StingIR 640

Thermal Clip-On Systems

PART #3152751013ST21

0 reviews | Write a review


Description And features


The AGM StingIR 640 miniature handheld observational thermal monocular is equipped with a 640×480, 12 micron, sub-25mK thermal detector and high-resolution OLED display. The StingIR is a full-featured unit, weighing less than 7 ounces/200 grams. The monocular can be helmet mounted for hands-free operations, or used as a standalone handheld device. The SingIR with included weapon mounts can also be used as a stand-alone thermal scope, or thermal clip-on, making it one of our most versatile offerings.

Other features include a digital compass, inclinometer, up to 8x digital zoom and the ability to be powered by two types of replaceable CR123 or 18650 batteries. The high-sensitivity built-in thermal detector provides you with a clear view in any lighting condition. The monocular is suitable for security enforcement, outdoor hunting, wilderness exploration, search and rescue and other fields.

Warning: California's Proposition 65



  • 12μm high-sensitivity detector
  • Head- or helmet-mountable for hands-free usage
  • Compact, sturdy design
  • High-resolution OLED display
  • Multiple thermal image palettes
  • Device supports up to 8× digital zoom
  • Powered by one CR123A/RCR123 or 18650 Lithium battery
  • Up to 5 hours continuous running
  • Digital compass and inclinometer
  • Type-C interface
  • 5-Year warranty



Characteristics

Refresh rate: 50 Hz

Resolution: 640×480

FOV: 16.3° × 12.3° (H × V)

Package Includes
  • Monocular
  • Helmet adapter bracket
  • Picatinny mount
  • Clip-on mount
  • 18650 battery cap
  • USB Type-C cable
  • Operation manual
  • Packing Case
Export Restrictions:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.


Specifications


Digital Compass
Yes
Palettes
WhiteHot, BlackHot, OrangeHot, Rainbow
Exit Pupil Diameter
12 mm
Magnification
1x - 8x
Detector type
12 μm Uncooled VOx Microbolometer
FFC (Flat Field Correction)
Auto (1 to 10 min. interval) or Manual
Refresh rate
50 Hz
Resolution
640×480
Detection Range (6' object)
1200 m
Field of view (H × X)
16.3° × 12.3° (H × V)
Digital zoom
1×, 2×, 4×, 6×, 8×
Diopter adjustment range
-5 to +2 dpt
Monitor
1024×768 OLED
Video output
PAL video output via USB port
Battery Type
One CR123A(3V) or RCR123(3.7V) or 18650(4.2V)
Battery Operating Time
CR123A - up to 2.5 hours / RCR123 - up to 1.5 hours / 18650 - up to 4.5 hours
External power supply
5 VDC/2 A, 1.5 W
Operating Temperature Range
-20°C to 50°C (-4°F to 122°F)
Weight
220 g (7.8 oz)
Overall Dimensions
140 × 70 × 50 mm (5.5 × 2.7 × 2.0 in)
