Thermal Clip-On Systems

0 reviews | Write a review

Description And features

The NEW AGM Rattler-C V2 series of thermal clip-ons boasts a industryleading 12 micron, sub-20mk thermal detectors (NETD <20mK for 384 and 640 models). These physical attributes provide users with some of the best image quality AGM has produced to date with potential detection ranges up to 2600 yards. The Rattler-C V2 thermal clip-ons have a high-sensitivity sensor, which provides a clear image under harsh environment conditions like darkness, fog, smoke, dust, rain, snow, wood, camouflage, etc. The Rattler-C V2 clip-on The Rattler TC can easily be attached in front of day scopes to quickly convert a day optic into a thermal imaging device without any special tools or equipment required. Powered replaceable and rechargeable Li-ion battery the AGM Rattler-C V2 provides up to 11 hours of continuous battery life on a single charge (2 batteries included). An external 5V power bank (battery pack) can be easily connected via a USB-C connector for a significant increase of operating time. Onboard Wi-Fi module is also available for live video streaming and video/images recording via mobile application.

Warning: California's Proposition 65

  • Quick conversion of daytime optics into thermal imaging scope
  • 12μm high-sensitivity thermal detector, NETD < 20mK
  • Fast 50Hz imaging
  • High resolution OLED display
  • Adjustable color palettes
  • On-board video/audio recording and image capture
  • Built-in EMMC storage (16 GB)
  • Shot Activated Recording (SAR)
  • Wi-Fi data transmission
  • Stadiametric rangefinder
  • Standby mode
  • 9 - 11 hours battery life (depending on model)
  • External power supply compatibility
  • Waterproof & shockproof
  • 5-year warranty

Detector type: 12μm VOx Uncooled Focal Plane Array

Refresh rate: 50 Hz

Resolution: 256 x 192

FOV: 9.3° × 6.9°

Package Includes
  • Mount
  • Two Rechargeable Battery
  • Charger
  • USB Cable
  • Lens Cloth
  • Manual
  • Carrying Case
Export Restrictions:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.


Shot-Activated Recording


Max. Recoil

1000 g/0.4 ms


184 × 68 × 67 mm (7.2 × 2.7 × 2.6 in)

Flat Field Correction (FFC)

Auto, Manual, External Correction


Black hot, White hot, Red hot, Fusion

Exit Pupil Diameter

22 mm

Distance Measurement

Yes (Stadiametric

Scene Mode

Cold, Warm

Video Recording


Defective Pixels Correction (DPC)


Audio Recording


Detector type

12μm VOx Uncooled Focal Plane Array

Standby Mode


Refresh rate

50 Hz


256 × 192

Detection Range (6' object)

1000 m/yd



Lens system

19 mm; F/1.0


Less than 35 mK (25°C, F# = 1.0)

Optical magnification

Field of view (H × X)

9.3° × 6.9°

Hot Track


Eye relief

10 mm


0.39-inch, OLED, 1024×768


Built-in EMMC (16 GB)

Battery Type

4400mAh Replaceable and Rechargeable Li-ion Battery



Battery Life (Operating)

11.5 h (25°C, with hotspot off)

External power supply

5 VDC, 2 A, USB Type-C

Operating Temperature Range

-30°C to +55°C (-22°F to 131°F)


0.5 kg (1.10 lb)

Protection Level


Package Includes

Thermal Imaging Clip-On, Mount, Two Rechargeable Battery, Charger, USB Cable, Lens Cloth, Manual, Carrying Case

Focus Range

0.5 m to infinity
