PART #RATT50-640-V3
2 reviews | Write a review
Although it seems like just yesterday the celebrated AGM Rattler thermal riflescope family got upgraded with the introduction of the RattlerV2’s, the NEW RattlerV3 LRF 50-640 testifies to the fact that evolution never stops. The RattlerV3 LRF 50-640 brings the once inconceivable new in-lens LRF technology to the compact Rattler series, the first thermal riflescope in a non-30mm tube style to get this treatment. Not only that, but the RattlerV3 LRF 50-640 also pairs an incredible new 2560x2560 high resolution display with an industry-leading sub-15mK thermal sensor, which combines to produce the best 640 resolution thermal image that we have ever produced. These technical parameters work together to produce a detection range 2.2 miles. This new high resolution display also allows two new, extremely popular, red and green monochrome color palettes, which were not available in current V2 models.
Its also the first Rattler ever to come with a shutterless NUC system, which allows for non-freezing algorithmic adjustments to the image while in use. It also works to raise the base magnification of the RattlerV2 50-640 from 2.5X to 3.5X, making it an optimal option for predator hunters in wide-open terrain, which entices longer range engagements. Users are also now able to view their photo/video content directly on the device itself, without having to view through the AGM Connect App, or manually downloaded via computer. The RattlerV3's newly optimized imaging algorithm comfortably places this unit amongst the best 640 images on the entire market. AGM - Vision Without Limits.
Warning: California's Proposition 65
Detector type: 12μm Uncooled
Refresh rate: 50 Hz
Resolution: 640×512
Base Magnification: 3.5× - 28×
FOV: 8.7° × 7.0°
Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
$5,295.00
Quick Order
Add to cart
FIRMWARE UPDATE INSTRUCTION
Please read the instructions below before updating the firmware.
Check current firmware version of your device, for this go to your device’s main menu to option “Info” or “Version” and check what number you have. Compare the number with the latest version of the firmware on the AGM website.
Download the firmware update package to your PC and unzip it.
NOTE: Do not open the DAV or BIN file on your computer as it may corrupt the file.
WARNING:
If your device does not have a built-in rechargeable battery and is powered by replaceable Lithium batteries, remove the batteries from the battery compartment before connecting the device to your PC, or it may cause computer damage.
If you removed the batteries, please make sure the device is connected to the computer during the update process. Otherwise, the device will shut off and may cause unnecessary upgrade failure, firmware damage, etc.
Please check the latest firmware. Click the FW Version to download the firmware update package.
AGM Rattler V3 LRF 35-384, AGM Rattler V3 LRF 35-640, AGM Rattler V3 LRF 50-640, AGM EVOLVER LRF 1280, AGM Adder V2 LRF 35-384, AGM Adder V2 LRF 35-640, AGM Adder V2 LRF 50-640, AGM Adder V2 LRF 60-1280, AGM Spectrum LRF 4K
Firmware Versions:
1. Main updates:
1. Updated for only Spectrum LRF 4K to implement and align with new functionality.
① LRF Box Display Update:
- Add the Rangefinding Reticle Style option in the Laser Ranging. (3 types)
- Add the Rangefinding Reticle Color option in the Laser Ranging. (8 colors)
② Add reticle Opacity adjustment option. There are a total of 5 gear levels.
③ Privacy and Device Security Updates (CE-RED Directive Update)
④ Fixed the issue of small-angle jumps of the BDC impact point.
⑤ Fixed other minor defects on digital scopes to improve usability.
2. Update all four models. (RattlerV3, AdderV2, Evolver & Spectrum LRF 4K)
① Supports using the shortcut key combination(LRF + Capture) to quickly enable/disable ballistic calculation in the main preview interface. (When the Reticle is enabled)
② "Opacity" has been renamed to "Reticle Brightness."
③ Fixed the rangefinding info overlapped with the rangefinding reticle under specific conditions.
④ Fixed minor defects during integration with the AGM Connect APP.
3. Update for only thermal scopes RattlerV3, AdderV2, Evolver.
① The working logic of the PIP view center has been updated.
When
ballistic calculation is enabled, the PIP view will be centered around
the BDC impact point. This resolves the issue where the BDC impact point
goes outside the PIP view when zooming in or at long distances.
Note:
When
BC is not enabled, the logic remains unchanged. The PIP center will
still follow the priority order: Reticle Center / LRF Rangefinding
Reticle / Main View Center.
Due
to differences in functionality and hardware across models, the
implementation of this feature may vary between different models.
1. 384 models: When BC is enabled, the PIP view will always center around the BDC impact point.
2. 1280 models: When BC is enabled, the PIP view will always center around the BDC impact point. (AdderV2-1280 & Evolver)
3. 640 models: Due to underlying algorithm limitations, this feature conflicts with the Zoom Pro functionality on the 640 model.
Therefore, an improvement solution will be implemented on the 640 models.
When ballistic calculation is enabled:
If Zoom Pro is not enabled, the PIP will center around the BDC impact point.
If Zoom Pro is enabled, the PIP will switch to being centered around the reticle center.
A prompt will be displayed to the user when enabling/disabling Zoom Pro.
