AGM TAIPAN TM25-384

AGM TAIPAN TM25-384

Name: AGM TAIPAN TM25-384
Brand: AGM
SKU: 3092451004TA21
Price: 1755.0000 USD
Availability: InStock
Rating: 5 (4 reviews)

PART #3092451004TA21

4 reviews | Write a review

Description And features

The AGM Taipan thermal monoculars have become synonymous with two words: Reliability and Simplicity. The Taipan TM25-384 is a great mid-level thermal monocular for anyone wanting to experience the capabilities of thermal imaging. Equipped with a highly advanced 12 micron 384x288 resolution thermal sensor and a 1280x960 LCOS display, it’s a great tool for hunters, campers and general outdoors enthusiasts who want or need to detect the presence of other animals or people in complete darkness. The range of uses include blood-tracking for hunters which aids in game retrieval, enhancing safety and awareness for hikers and camp sites and general nighttime curiosity. The Taipan TM25-384 still comes equipped with many of the most popular software features that experienced thermal users have come desire: up to 7.5 hours of battery life from an internal rechargeable battery, Wi-Fi hotspot, AGM Connect app compatibility for exporting and sharing images and videos, 2.5-20X magnification, 8GB of internal storage with no need for a memory card and a 5 Year Transferable Warranty.

Warning: California's Proposition 65

FUNCTIONS:

Distance Measurement:
The device realizes distance measurement function after marking the top and bottom of target, and input the target height.

Hot Spot Mark:
The device detects and marks the hot spot of highest temperature.

Mode Switch:
Device supports pallet switch and distance measurement.

Storage:
Built-in memory module supports video recording/snapshot capturing.

Digital Zoom:
Device supports 1×, 2×, 4×, and 8× digital zoom.

Wi-Fi Hotspot:
Device can capture snapshots, record videos, and set parameters via APP after being connected to your phone.

384×288 resolution, 12 μm, high sensitivity detector
Adaptive AGC, DDE, 3D DNR
1280 × 960 resolution 0.4-inch LCOS display
Built-in rechargeable Lithium battery
More than 7.5 hours continuous running (with Wi-Fi hotspot function off)
Wi-Fi hotspot
Type-C interface
5-Year warranty

Characteristics

Detector type: Vanadium Oxide Uncooled Focal Plane Arrays

Refresh rate: Sensor / LCOS display 50 Hz

Resolution: 384x288

FOV: 10.5° × 7.9°

Package Includes

USB Cable
Lanyard
EU Plug
Lens Cloth
Operation Manual

Downloads

Data Sheet

User Manual

Export Restrictions:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.

$1,755.00

Compare

Quick Order

Add to cart

Specifications

Interface

USB Type-C

Pixel Interval

12 μm

Multi Language menu

Yes

Drop Test Height

1.5 m (4.9 feet)

Magnification

2.5x - 20x

Detector type

Vanadium Oxide Uncooled Focal Plane Arrays

Response Waveband

8μm to 14μm

FFC (Flat Field Correction)

Auto, Manual, External Correction

Highest Temperature Spot Tracking

Yes

Standby Mode

Yes

Refresh rate

50 Hz

Aperture

F1.0

Resolution

384×288

Detection Range (6' object)

1180m/yd

NETD

Less than 35 mk (@25°C), F#=1.0

Lens (focal length)

25 mm

Power

5 VDC/2 A, 1.5 W

Field of view (H × X)

10.5° × 7.9° (H × V)

Digital zoom

2×, 4×, 8×

Monitor

1280×960, 0.4 inch, LCOS

Imaging palettes

Black Hot, White Hot, Red Hot, Fusion

Storage

Built-in memory module (8 GB)

Record Video

On-board video recording

Capture Snapshot

Yes

Battery Type

Built-in rechargeable Lithium battery

Wi-Fi

Yes

CVBS Output

Yes (via USB)

Battery Operating Time

-20°C to 55°C (-4°F to 131°F)

Battery Capacity Display

Yes

Weight

300 g (0.69 lb)

Working Temperature/ Humidity

-20°C to 55°C (-4°F to 131°F)

Overall Dimensions

171 × 61 × 57 mm (6.73 × 2.4 × 2.2 in)

Protection Level

IP67

Firmware update

FIRMWARE UPDATE INSTRUCTION

Please read the instructions below before updating the firmware.

Check current firmware version of your device, for this go to your device’s main menu to option “Info” or “Version” and check what number you have. Compare the number with the latest version of the firmware on the AGM website.

Download the firmware update package to your PC and unzip it.

NOTE: Do not open the DAV or BIN file on your computer as it may corrupt the file.

Connect the thermal device to your PC with USB cable.
Turn on the thermal device.
Disable the Wi-Fi Hotspot function in the device menu if WiFi is enabled.
Open the detected disk (USB drive) in file manager program. Copy the unzipped .dav file and paste it to the root directory of the device.
Turn off the device.
Turn on the device. After a while, the firmware update process will start automatically. During the update, the screen will display the inscription "Upgrading ...". The update process will be completed when the inscription "Upgrading ..." goes out. Repeat steps 4-6 for each updating file.
Turn off the device and disconnect it from your PC.

WARNING:
If your device does not have a built-in rechargeable battery and is powered by replaceable Lithium batteries, remove the batteries from the battery compartment before connecting the device to your PC, or it may cause computer damage.

If you removed the batteries, please make sure the device is connected to the computer during the update process. Otherwise, the device will shut off and may cause unnecessary upgrade failure, firmware damage, etc.

To begin the procedure for updating the firmware of your equipment, you must confirm that you are familiar with and agree to the "AGM GLOBAL VISION" Export Policy («AGM GLOBAL VISION» Export Policy). By continuing the process of updating your device, you are confirming that you received this device legally and in compliance with all applicable US export laws and that you are not on the Banned Persons List and/or are not affiliated with any of the Banned Persons as defined by the US Government.
If these conditions are met, please check the box on the left and follow the instructions for updating the hardware firmware.

Please check the latest firmware. Click the FW Version to download the firmware update package.

AGM TAIPAN TM15-384 / AGM TAIPAN TM19-384 / AGM TAIPAN TM25-384 THERMAL MONOCULAR SERIES FIRMWARE

Firmware Versions:
- V5.5.53_230113
  - Fixed an issue when updating firmware on some devices that could result in a solid screen and buttons not working.

  - Support 1-10 levels of brightness and contrast adjustment.
  - Support m/yard display for distance measurement.
  - Digital Zoom display (1.5X - 3X - 6X - 12X; 2X - 4X - 8X - 16X; 2.5X - 5X -10X -20X)
- V5.5.41_220713
  - Ukrainian is added in the Language menu. English is language by default.
- V5.5.39_220510
  Fixed the following defect:

  -The menu won't work by accident.
- V5.5.39_220421
  - Repacked firmware. All the features keep the same.
  - FPGA FW integrated into Main FW
- V5.5.21_220127
  - Support "Auto Power Off."
  - Support "Time Sync."
  - Support "Burn-Prevention."
- V5.4.26_210827
  - Repacked firmware. All the features keep the same.
- V5.4.26_201120
  - Basic version.
