AGM SIDEWINDER TM35-640

AGM SIDEWINDER TM35-640

Name: AGM SIDEWINDER TM35-640
Brand: AGM
SKU: 3142551005SI31
Price: 2495.0000 USD
Availability: OutOfStock
Rating: 5 (1 reviews)

PART #3142551005SI31

1 reviews | Write a review

Description And features

The AGM Sidewinder Thermal Monocular series is the newest addition to what is already the most extensive thermal product assortment in the world! The Sidewinder TM35-640 boasts a 35mm Germanium lens and a 640x512, 12 micron, sub-20mK thermal detector which combine to provide users with an 1800 yard detection range, and one of the most detailed thermal images to date. The Sidewinder also brings many new advancements to the product category which users have been clamoring for. This handheld monocular comes equipped with the most sensitive thermal sensor on the market, providing users with a stunning advancement in image clarity and background detail. Also, this unit utilizes a removable, non-proprietary 18650 rechargeable battery which powers the unit by offering up to 5 hours of operating time, built-in to a new robust rubber armored housing for added durability and protection.

The Sidewinder also comes packed with numerous software improvements, and many features that have become commonplace within the AGM thermal product assortment: 50Hz refresh rate, 64GB of built-in memory (highest in its class), Wi-Fi compatibility to pair with the AGM Connect App, an IP67 waterproof rating, F1.0 aperture, USB Type-C port for external power capabilities, 4 color palettes and an industry-leading 5 Year Transferable Warranty. The Sidewinders are built for well-rounded use and would work great for hunting, farming/herd protection, building security, law enforcement, search & rescue, boating, camping and other general outdoors activities.

Warning: California's Proposition 65

12μm, 640×512 resolution detector
Highest thermal sensitivity (NETD <20mK)
Advanced image processing (Digital Detail Enhancement, digital Noise Reduction and NLM algorithm)
50 Hz image frame rate
1024×768 resolution OLED display
Built-in memory supports video/audio recording and snapshot capturing
64 GB memory module
Wi-Fi hotspot
1×, 2×, 4× and 8× digital zoom
Replaceable and rechargeable Li-Ion battery
Up to 7 hours continuous running
External power supply capability
Waterproof
5-Year warranty

Characteristics

Detector type: Vanadium Oxide Uncooled Focal Plane Arrays

Refresh rate: 50 Hz

Resolution: 640 × 512

FOV: 12.5° × 10°

Package Includes

Battery Charger
USB Cable
Power Adapter (US and EU plugs included)
18650 Rechargeable Battery
Lens Cloth
Wrist Strap
Carrying Case
User Manual
Protective Bag

Downloads

Data Sheet

User Manual

Export Restrictions:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.

Sold out

Specifications

Palettes

Black Hot, White Hot, Red Hot, Fusion

Dimensions

188 × 58 × 65 mm (7.4 × 2.3 × 2.6 in)

Interface

USB Type-C

Pixel Interval

12 μm

Magnification

2× - 16×

Detector type

Vanadium Oxide Uncooled Focal Plane Array

Response Waveband

8μm to 14μm

FFC (Flat Field Correction)

Auto, Manual, External Correction

Highest Temperature Spot Tracking

Yes

Standby Mode

Yes

Refresh rate

50 Hz

Resolution

640x512

Detection Range (6' object)

1800 m

Lens (focal length)

35 mm

Power

5 VDC/2 A, 1.75 W

Field of view (H × X)

12.5° × 10°

Digital zoom

1×, 2×, 4×, 8×

Diopter adjustment range

-5 to +3 dpt

Monitor

1024×768, OLED

Storage

Built-in memory (64 GB)

Record Video

Yes / Yes (on-board)

Capture Snapshot

Yes

Battery Type

One 18650 Replaceable rechargeable Lithium battery

Wi-Fi

Yes

Battery Operating Time

Up to 7 hours

Weight

505 g (1.11 lb)

Working Temperature/ Humidity

-30°C to 55°C (-22°F to 131°F)

Protection Level

IP67

Firmware update

FIRMWARE UPDATE INSTRUCTION

Please read the instructions below before updating the firmware.

Check current firmware version of your device, for this go to your device’s main menu to option “Info” or “Version” and check what number you have. Compare the number with the latest version of the firmware on the AGM website.

Download the firmware update package to your PC and unzip it.

NOTE: Do not open the DAV or BIN file on your computer as it may corrupt the file.

Connect the thermal device to your PC with USB cable.
Turn on the thermal device.
Disable the Wi-Fi Hotspot function in the device menu if WiFi is enabled.
Open the detected disk (USB drive) in file manager program. Copy the unzipped .dav file and paste it to the root directory of the device.
Turn off the device.
Turn on the device. After a while, the firmware update process will start automatically. During the update, the screen will display the inscription "Upgrading ...". The update process will be completed when the inscription "Upgrading ..." goes out. Repeat steps 4-6 for each updating file.
Turn off the device and disconnect it from your PC.

WARNING:
If your device does not have a built-in rechargeable battery and is powered by replaceable Lithium batteries, remove the batteries from the battery compartment before connecting the device to your PC, or it may cause computer damage.

If you removed the batteries, please make sure the device is connected to the computer during the update process. Otherwise, the device will shut off and may cause unnecessary upgrade failure, firmware damage, etc.

To begin the procedure for updating the firmware of your equipment, you must confirm that you are familiar with and agree to the "AGM GLOBAL VISION" Export Policy («AGM GLOBAL VISION» Export Policy). By continuing the process of updating your device, you are confirming that you received this device legally and in compliance with all applicable US export laws and that you are not on the Banned Persons List and/or are not affiliated with any of the Banned Persons as defined by the US Government.
If these conditions are met, please check the box on the left and follow the instructions for updating the hardware firmware.

Please check the latest firmware. Click the FW Version to download the firmware update package.

AGM SIDEWINDER TM25-384, AGM SIDEWINDER TM35-384, AGM SIDEWINDER TM35-640, AGM SIDEWINDER TM50-640

Firmware Versions:
- V5.5.61_231008
  Optimized the following contents:
  # New user interface.
  # Support Tone (Cold/Warm) mode.
  # Support 1-10 levels of sharpness adjustment.
  # Improved audio recording performance.
  # Add Ukrainian in the Language menu but show English by default.
