AGM ObservIR LRF 50-640

PART #OBSE50-640

0 reviews | Write a review


Description And features


The AGM ObservIR LRF Thermal & Digital Day/Night Vision binoculars are some of the most technologically advanced and feature-packed digital devices in the world. The primary engine behind these binoculars lies within the main thermal viewing channel, with its high-sensitivity 12 micron detector. Unlike other thermal binoculars on the market, the ObservIR LRF also come outfitted with a digital day/night  channel as well, which is great for aiding in recognition of targets detected by the thermal channel. The built-in 1,000 m laser rangefinder simply takes the ObservIR LRF to another level, and this is without even mentioning its 64 GB of internal memory and Wi-Fi compatibility.
The ObservIR LRF binoculars also come packed with numerous software improvements, and many features that have become commonplace within the AGM thermal product assortment: high-sensitivity thermal detector, 50 mm objective lens with a 1.0 aperture, 3840x2160 ultra-low light CMOS sensor, various viewing modes, multiple color palettes, picture-in-picture mode, built-in laser rangefinder, GPS module, long-range IR illuminator, up to 8.5 hours of battery life on removable, rechargeable battery pack, USB Type-C port for external power capabilities, IP67 waterproof rating. The package includes two battery packs, wrist strap, tripod adapter and charger.

Warning: California's Proposition 65

  • Dual-spectrum thermal and digital day/night system
  • 12μm high-sensitivity thermal sensor
  • Superior sub-15 millikelvin thermal sensitivity
  • 640x512 thermal resolution
  • 4.5x – 20x thermal magnification
  • New Image Boost 3.0 algorithm
  • Ultra-low illumination digital channel
  • 3840×2160 digital resolution
  • Built-in IR illuminator
  • Eye-safe 1,000 m laser rangefinder
  • 1920×1080 resolution, 0.49-inch OLED display
  • Digital Magnetic Compass
  • Built-in GPS module
  • Video/audio recording and snapshot capture
  • Built-in 64 GB EMMC storage
  • Wi-Fi hotspot
  • Standby mode
  • 8.5 hours of continuous operation on a single charge
  • Auto screen-off function to saving energy
  • External power supply capability
  • Waterproof and dustproof
Package Includes
  • Two NE-7255 Li-ion Batteries 7.18 V/5400 mAh
  • NE-7255 Battery Charger
  • USB-C to UCB-C Cable (fast charging)
  • USB-A to USB -C Cable
  • Power Adapter
  • Tripod Adapter
  • Quick Start Guide
  • Neck Strap
  • Lens Cloth
  • Owners Manual
Export Restrictions:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.

$5,495.00

Compare

Quick Order

Add to cart


Specifications


Interpupillary Distance
60 mm to 74 mm
Safety Class for Laser
Class 1
Palettes
Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome Image Modes: Day, Night, Green, Yellow, Auto
Dimensions
229 x 148 x 80 mm / 9.0 x 5.8 x 3.1 in
Infrared Illuminator
Built-in 850nm Smart IR.Power and beam angle adjustment.
Distance Measurement
Laser Rangefinder: up to 1,000 m, ±1 m accuracy
Scene Mode
Jungle, Recognition
Video Recording
Yes
Audio Recording
Yes
Magnification
Thermal Channel - 4.5x - 20x / Optical Channel - 5.5x – 22x
Detector type
Thermal Detector - 12μm VOx Uncooled Focal Plane Array / Digital Sensor - 3840×2160, 1/1.8” Progressive Scan CMOS
FFC (Flat Field Correction)
Auto, Manual, External Correction
Highest Temperature Spot Tracking
Yes
Standby Mode
Yes
Refresh rate
50 Hz
Resolution
640 × 512
Laser Wavelength
905 nm
Detection Range (6' object)
1,800 m
Snapshot
Yes
Lens system
Thermal Channel - 50 mm; F1.0 / Optical Channel - 60 mm, F2.2
NETD
Less than 15 mK (25°C, F#=1.0)
Field of view (H × X)
Thermal Channel - 8.8 x 5.3 / Optical Channel - 7.3°× 4.1°
Diopter adjustment range
-5 to +3
Monitor
1920×1080, 0.49 inch, OLED, 50 FPS
Display
Day, Night, Auto
Storage
64 GB EMMC
Battery Type
One Replaceable and Rechargeable NE-7255 Li-ion Battery 7.18 V/5400 mAh (Two NE-7255 Li-ion Batteries 7.18 V/5400 mAh included)
Wi-Fi
Yes
Battery Life (Operating)
8.5 hours
Power supply
5 VDC/2 A, USB Type-C interface. Supports external power supply.
Operating Temperature Range
-20°C to 55°C (-4°F to 131°F)
Weight
0.83 kg / 1.82 lb
Protection Level
IP67 (Waterproof)

Firmware Updates


FIRMWARE UPDATE INSTRUCTION

Please read the instructions below before updating the firmware.

Check current firmware version of your device, for this go to your device’s main menu to option “Info” or “Version” and check what number you have. Compare the number with the latest version of the firmware on the AGM website.

Download the firmware update package to your PC and unzip it.

NOTE: Do not open the DAV or BIN file on your computer as it may corrupt the file.

  1. Connect the thermal device to your PC with USB cable.
  2. Turn on the thermal device.
  3. Disable the Wi-Fi Hotspot function in the device menu if WiFi is enabled.
  4. Open the detected disk (USB drive) in file manager program. Copy the unzipped .dav file and paste it to the root directory of the device.
  5. Turn off the device.
  6. Turn on the device. After a while, the firmware update process will start automatically. During the update, the screen will display the inscription "Upgrading ...". The update process will be completed when the inscription "Upgrading ..." goes out. Repeat steps 4-6 for each updating file.
  7. Turn off the device and disconnect it from your PC.

WARNING:
If your device does not have a built-in rechargeable battery and is powered by replaceable Lithium batteries, remove the batteries from the battery compartment before connecting the device to your PC, or it may cause computer damage.

If you removed the batteries, please make sure the device is connected to the computer during the update process. Otherwise, the device will shut off and may cause unnecessary upgrade failure, firmware damage, etc.

Please check the latest firmware. Click the FW Version to download the firmware update package.

  • AGM ObservIR LRF 50-640 & AGM ObservIR LRF 60-1280

    Firmware Versions:

    • V5.5.150_260119

      1. Remove the activation pop-up that appears after powering on for the first time or restoring the product to factory settings and connecting it to the app.

      2. Fix some minor bugs to improve usability.
