AGM Adder TS50-640

PART #3142555006DTL1

0 reviews | Write a review


Description And features


The AGM Adder Thermal Riflescopes pack all the technology and advanced electronics into the historically familiar 30mm tube riflescope housing. The Adder TS50-640 pairs a 50mm Germanium lens with an upgraded sub-35mK 640x512 thermal detector and a 1024x768 OLED display, to provide one of the best images AGM has produced to date. The combination of the 12 micron sensor with the 50mm lens also places the base magnification for this unit right in the sweet spot in terms of flexibility for both hog and predator hunters, at 2.5X. This magnification level isn’t too high and restrictive on the hunter’s field of view and is simultaneously just high enough to ensure there isn’t too much resolution degradation when digitally zooming to 5X and 10X. Other enhancements include an astonishing 14+ hours of battery life on two internal 18650 rechargeable batteries, 5 internal reticle options, and shot-activated video recording, which, when enabled, ensure that hunters forgetting to press the record button is a thing of the past!

The entire Adder product family also comes with a high-quality, one-piece, 30mm quick-detach mount from American Defense Manufacturing. These mounts allow for sliding the scope both forward and backwards to provide optimal eye relief for shooters using a wide array of different shooting platforms. Other features include, but aren’t limited to: 50 Hz refresh rate, IP67 waterproof rating, external power capability, 64GB of on-board memory, 5 different reticle options, Wi-Fi and AGM Connect app compatibility, multiple color palettes, audio recording, emergency CR123 battery power, and of course AGM’s 5 Year Transferable Warranty.

Warning: California's Proposition 65

  • 640×512 thermal resolution
  • 12μm high-sensitivity detector
  • Fast 50 Hz imaging
  • High-resolution OLED display
  • 1x, 2x, 4x, 8x digital zoom
  • On-board video and audio recording
  • Shot Activated Recording (SAR)
  • Wi-Fi data transmission
  • Fast 64GB EMMC built-in storage
  • Various reticle types and colors
  • Adjustable color palettes
  • Standby mode
  • Waterproof & Shockproof
  • Dual power system
  • Up to 13 hours continuous working
  • External power supply capability
  • 5-Year warranty
Characteristics

Refresh rate: 50 Hz

Resolution: 640×512

FOV: 8.8° × 7.0°

Export Restrictions:

Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.


Specifications


Palettes

Black Hot, White Hot, Red Hot, Fusion

Reticle

5 types, 4 colors, on/off

Boresight Adjustment

Digital Controlled

Boresight Increment

0.15 mil / 0.51 MOA

Distance Measurement

Yes (Stadiametric)

Scene Mode

Jungle, Recognition

Picture In Picture Mode (PIP)

Yes

Video Recording

Yes

Defective Pixels Correction (DPC)

Yes

Uniformity Correction

Auto, Manual, External Correction

Digital Magnification

2.5x - 20x

Detector type

12μm, Uncooled, 50 Hz, < 35 mK (25°C, F# = 1.0)

Standby Mode

Yes

Resolution

640 × 512

Detection Range (6' object)

2600 m/yd

Lens system

50 mm; F/1.0

Field of view (H × X)

8.8° × 7.0°

Digital zoom

1×, 2×, 4×, 8×

Diopter adjustment range

-5 to +5 dpt

Eye relief

≥ 60 mm

Display

1024×768, 50 Hz, OLED

Storage

64 GB EMMC

Battery Type

Two 18650 Rechargeable Batteries (built-in) and one CR123 Battery

CVBS Output

Yes (via USB)

Battery Life (Operating)

Up to 13 hr

Power supply

5 VDC/2 A, USB Type-C Supports QC3.0

Operating Temperature Range

-30°C to +55°C (-22°F to +131°F)

Degree of Protection

IP67

Weight

970 g ( 2.14 lb)

Overall Dimensions

420 × 78 × 82 mm (16.5 × 3.1 × 3.2 in)

Magnification

2.5×


Firmware update


FIRMWARE UPDATE INSTRUCTION

Please read the instructions below before updating the firmware.

Check current firmware version of your device, for this go to your device’s main menu to option “Info” or “Version” and check what number you have. Compare the number with the latest version of the firmware on the AGM website.

Download the firmware update package to your PC and unzip it.

NOTE: Do not open the DAV or BIN file on your computer as it may corrupt the file.

  1. Connect the thermal device to your PC with USB cable.
  2. Turn on the thermal device.
  3. Disable the Wi-Fi Hotspot function in the device menu if WiFi is enabled.
  4. Open the detected disk (USB drive) in file manager program. Copy the unzipped .dav file and paste it to the root directory of the device.
  5. Turn off the device.
  6. Turn on the device. After a while, the firmware update process will start automatically. During the update, the screen will display the inscription "Upgrading ...". The update process will be completed when the inscription "Upgrading ..." goes out. Repeat steps 4-6 for each updating file.
  7. Turn off the device and disconnect it from your PC.

WARNING:
If your device does not have a built-in rechargeable battery and is powered by replaceable Lithium batteries, remove the batteries from the battery compartment before connecting the device to your PC, or it may cause computer damage.

If you removed the batteries, please make sure the device is connected to the computer during the update process. Otherwise, the device will shut off and may cause unnecessary upgrade failure, firmware damage, etc.

Please check the latest firmware. Click the FW Version to download the firmware update package.

  • AGM ADDER TS35-640 / AGM ADDER TS50-640 THERMAL IMAGING SCOPES FIRMWARE

    Firmware Versions:

    • V5.5.53_221202

      -Support 1-10 levels for brightness and contrast adjustment.
      -Keep the reticle’s original position without jumping when zooming.
      -Name change. Reticle Group->Zeroing Profiles, Reticle->Zeroing
      -Delete the wheel button function: Press/switch reticle type. When you press the button, no change will occur, so as to avoild the misoperation.

    • V5.5.40_220627_640

      - Basic version.
